Epson SureColor SC-F530 Desktop Dye-Sublimation Textile Printer

Designed for creativity, built for convenience
Meet the creative demands of your customers without the added time and cost to your business with the 24-inch Epson SC-F530 dye-sublimation printer. Built and designed to provide the user with ease of use, greater productivity and exceptional efficiency, the SC-F530 encompasses the convenient Epson Total Solutions, LFP Accounting Tool, and a printer design that requires little time to operate and maintain. Economically ideal for small businesses with a lower print volume.
  1. 24-inch Dye-Sublimation Printer
  2. CISS ink tank with CYMK ink
  3. High-performance dye-sublimation transfer printer
  4. Ideal for small-volume clothing and custom merchandise




Printing:

Printing Technology:PrecisionCore Inkjet Technology
Variable-Sized Droplet Technology
Printhead: PrecisionCore TFP PrintheadNozzle Configuration:3,200 nozzles (800 nozzles x 4 channels x 1 head)Maximum Print Resolution:2400 x 1200 dpiPrint Speed:Production (2 pass), For Fabric: Up to 62sec / 21m2 (600 x 1200 dpi)
Production (7 pass): For Fabric & Rigid: Up to 208sec / 7.5m2 (1200 x 1200 dpi)
Production (12 pass), For Fabric & Rigid: Up to 350sec / 4.5m2 (2400 x 1200 dpi)

Ink:

Ink Type:Epson Genuine Dye-Sublimation InkColours:Cyan, Magenta, Yellow, BlackInk Capacity:140ml

General:

Dimensions:Storage (W x H x D): 970mm x 245mm x 577mm
Printing (W x H x D): 970mm x 245mm x 811mmWeight:29kg

Printer Details:

Options:Optional Stand - 24", Roll Feed Spindle - 24"

Power:

Power Consumption:Operating: Approx. 22W
Ready: Approx. 8W
Sleep: Approx. 1.6W
Power Off (Stand by): Approx. 0.2WRequirement:AC 100 to 240V 50/60HzRated Current:1.4ATemperature & Humidity:Operating Temperature: 10°C to 35°C, Storage/Packing: -20°C to 60°C, Unpacking: -20°C to 40°C
Operating Humidity: 20 to 80% (no condensation), Storage: 5 to 85% (no condensation)

Paper Handling:

Paper Path:Friction FeedPaper Size & Thickness:Paper Width (Roll): Roll Paper: 210mm to 610mm; Cutsheet: 210mm to 610mm; ASF: A4 to A3
Paper Thickness: Roll Paper: 0.05mm ~ 0.21mm; Cutsheet: 0.12mm ~ 0.27mm; ASF: 0.12mm ~ 0.27mmRoll Dimensions:Maximum Diameter / Weight: 110mm / 3kg

Control Panel:

Control Panel:4.3 Inch Touch Screen

Memory:

Main:1GB

Supported OS and Applications:

Utility:(Bundled in CD): Windows Install Navi, Printer Driver, EpsonNet Setup, EpsonNet Print, EpsonNet Config SE, Epson Software Updater, Epson Manuals, Manual Launcher, Epson Control Dashboard
(Web Delivery): Windows Install Navi, Web Installer, Firmware Updater, PS Driver, HDI Driver, XPS Driver, EpsonNet Setup Manager, Epson Device Admin, Epson Edge Dashboard, Epson Print Layout, LFP Accounting Tool, Adobe ICC Profiles, Mac Web Installer, Install Navi, Printer Driver, EpsonNet Config, Epson Software Updater, Uninstaller, Epson Manuals, Epson Media Installer, Firmware Updater, Linux, Printer Driver
